COMBINATION BEVEL PIVOT 200 MAGSWITCH

Pivot Angle -asennustyökalu kulmiin, jotka ovat 22-270 astetta.
Molemmissa varsissa on Magswitch On/Off magneetti, joissa on 91 kg pitovoima.

FEATURES

• On/Off Magswitch Magnet that truly stays clean.
• Incredibly strong –each side features a 200 lb. (91 kg).
• Magswitch Multi plane workholding on three sides of each magnet Pivot Range from inside 22 to 270 degree angles.
• Accommodates flat and pipe.
• Single lock on elbow for fast securing of your angle.
• Detents at every 45 deg. For rapid adjustment.
• Odd angles –Incredibly fast set ups -literally in seconds.
• No helping hand required. Get the job done by yourself with Magswitch.
• Magswitch offers incredible strength, versatility and precision and sets up in seconds.
• No wasted time cleaning magnet for use as is the case with older switching technology.Metal chips end up on floor, not in your finger!
• Don’t take unnecessary safety risks holding steel at odd angles with your hands –lets us help.

 SPECIFICATIONS

• Max Breakway: 200 lbs/90 kg
• Full Saturation Thickness: 3/16”/4.75mm
• 2:1 Shear Working Load: 48.4 lbs/22 kg
• Product Weight: 3.5 lbs/1.6 kg
• Overall Height: 90mm
• Magnetic Pole Footprint: 41.25mm x 56mm
